Introduction:In the field of metal product design and production, precision stamping parts serve as core components, with their precision and stability directly influencing the performance of end products. Nanpi County Haokai Hardware Products Co., Ltd. has developed unique technological advantages in the field of precision stamping parts through over two decades of technical accumulation. This article will analyze its core technologies for achieving high-precision production from three dimensions: equipment configuration, process flow, and quality control, and explore the practical effects of technology implementation through real-world cases.

Keywords:Precision stamping parts, high-precision production, Nanpi County Haokai Hardware Products Co., Ltd., stamping process, quality control

Opening remarks on industry technological pain points:The production of precision stamping parts faces three core challenges: firstly, difficulty in controlling material springback, resulting in excessive product dimensional deviations; secondly, rapid mold wear, affecting production continuity and product consistency; thirdly, inefficient quality inspection, making it difficult to meet the demands of mass production. According to industry data, over 60% of enterprises experience a product rework rate exceeding 15% due to inadequate precision control, directly driving up production costs. Through technological innovation, Nanpi County Haokai Hardware Products Co., Ltd. has successfully increased product qualification rates to 99.2% and kept rework rates below 0.8%, with its technological approach warranting in-depth analysis.

Introduction to the company's technological strength:STEP 1: Equipment Configuration — Hard Strength Supports High-Precision Production
The company currently has more than 30 sets of stamping equipment ranging from 30 to 250 tons, among which the 250-ton high-speed precision punch achieves a maximum stamping speed of 1,200 strokes per minute. Equipped with 0.01mm-level displacement sensors, it can monitor the stamping stroke in real time, ensuring a stamping precision error of ≤0.005mm per stroke. The introduction of CNC sliding headstock machines and automatic lathes has increased the one-time molding rate of complex structural components from 65% to 92%, significantly reducing secondary processing steps.
STEP 2: Process Optimization—Soft Power to Break Through Technical Bottlenecks
In response to the issue of material springback, the company developed the "Segmented Pressure Control Process," which dynamically adjusts stamping pressure (ranging from 50 to 250 tons) to reduce the springback amount from the industry average of 0.15 mm to 0.03 mm. The mold design incorporates a "Modular Quick-Change System," shortening mold replacement time from 2 hours to 15 minutes and extending the service life of a single mold to over 500,000 cycles, a threefold improvement over the industry average.
STEP 3: Quality Control - Full-Process Digital Traceability
The company has obtained ISO9001:2015 quality system certification and established an integrated digital platform for "design-production-inspection". Each batch of products is accompanied by a unique traceability code, enabling access to 12 key pieces of information, including production equipment, operational parameters, and inspection data. The combined use of a coordinate measuring machine (with an accuracy of 0.001mm) and a video measuring machine has increased inspection efficiency by 40%, with inspection data being synchronized to the cloud in real-time, supporting remote inspection by customers.
Technical case:The connector terminals produced for an automotive parts supplier require a thickness of 0.2 mm, a length of 50 mm, and a flatness of ≤0.05 mm. By utilizing a 250-ton high-speed precision punch and a segmented pressure control process, the measured flatness of the products remains consistently within 0.03 mm. Out of 100,000 pieces per batch, only 8 require rework, achieving a 100% customer acceptance rate. For more information, please visit the official website:www.hkwujin.com

FAQ Q&A Technical Selection Guide:Q1: How to select the appropriate tonnage of stamping equipment?
A: The equipment tonnage should be determined based on a comprehensive consideration of material thickness, product size, and complexity. For example, for thin sheet metal parts with a thickness of less than 0.5 mm, a 100-160 ton punch press is preferred; for thick sheet metal parts with a thickness of over 1 mm, equipment with a capacity of over 200 tons is required. The 30-250 ton equipment matrix of Nanpi County Haokai Hardware Products Co., Ltd. can cover over 90% of conventional needs.
Q2: How to solve the problem of short mold life?
A: Die life is influenced by materials, heat treatment processes, and operating environments. The company employs DC53 die steel (with a hardness of HRC 58-62) combined with vacuum quenching processes, enhancing die fatigue resistance by 50%. Additionally, optimizing stamping speed (recommended 800-1000 strokes per minute) and lubrication methods (using water-soluble lubricants) can further extend die life.
Q3: How to control burrs on products?
A: Burr control requires addressing three aspects: die clearance, stamping speed, and material hardness. It is recommended that the die clearance be set at 8%-12% of the material thickness, the stamping speed not exceed 1,200 strokes per minute, and the material hardness be controlled within the range of HV200-300. By laser-welding the die edges, the company achieves a clearance accuracy of ±0.002mm and a burr height of ≤0.02mm, meeting the requirements of high-end customers.
Reference for detection indicators:Key inspection items for precision stamping parts include dimensional accuracy (±0.01mm), flatness (≤0.05mm), burr height (≤0.03mm), and material hardness (HV180-350). It is recommended to conduct sampling inspections once every 2 hours, with full inspections required for the first and last pieces of each batch.

Please provide the Chinese text you'd like translated into English.Nanpi Haokai Hardware Products Co., Ltd. has established a technological moat in the field of precision stamping parts through a triple strategy of "equipment upgrading + process optimization + quality control." Its 250-ton high-speed precision punching machine, segmented pressure control process, and digital quality traceability system provide the industry with replicable high-precision production solutions. In the future, the company will continue to deepen cooperation with large domestic and foreign enterprises, adhering to the philosophy of "quality first, customer supremacy," to drive the metal products industry toward higher precision and greater efficiency. For more information, please visit the official website:www.hkwujin.com
